Rotel RCD-1572 Mk2


The RCD-1572 elevates performance by utilizing a purpose designed and built CD mechanism along with other circuit refinements. One of the RCD-1572’s most important features is the Wolfson WM8740 digital filter/stereo digital-to-analogue converter. Originally developed for high resolution sources, it is the product of extensive research and real world testing and processes digital signals up to 24-bits in length at sampling rates from 8 kHz to 192 kHz.

The post-converter analogue circuitry benefits from Rotel‘s decades-long experiences in crafting the finest sounding pathway from the DAC’s internal output to RCA and XLR rear panel connectors that bridge the gap between the RCD-1572 and down-stream components. All circuit components – resistors, capacitors, inductors – are chosen only after their positive contribution to sound quality were quantified and verified qualitatively by extensive listening sessions.

Kategorija: Žyma:

Total Harmonic Distortion (THD): 0.002% @ 1kHz

Frequency Response: 20Hz – 20kHz ±0.5dB

S/N Ratio (IHF „A” Weighted): >118dB

Dynamic Range: >99dB

Digital to Analog Converters: Wolfson 24-bit/192kHz

Channel Balance: ±0.5dB

Channel Separation: >115dB @ 10kHz

Dimensions (W × H × D):

431 × 104 × 320mm

17″ × 4″ × 12.6″

Front Panel Height: 2U / 88.1mm (3.5″)

Power Requirements: 230V, 50Hz

Power Consumption: 15W

Standby Power Consumption: <0.5W

Net Weight: 6.7kg (15lbs.)
