Frequency Response 75 Hz — 35 kHz

Sensitivity (1W@1M) 86 dB

System Configuration 2-Way

1 x 4″ C-CAM mid-range driver
1 x 1″ pivoting Gold Dome tweeter

Power Handling (RMS) 50 W

Maximum SPL 102.5 dBA

Recommended Amplifier Requirements 25 — 50 W

Nominal Impedance 8 ohms

Crossover Frequency 3.2 kHz

Dimensions (Including Frame (H x W x D)

301.5 x 301.5 x 77.5 mm (11^7/8 x 11^7/8 x 3^1/16„)

Cut-Out Dimensions

251 x 251 x 59.5 mm (9^7/8 x 9^7/8 x 2^5/16„)

Depth From Wall 18 mm (^3/4„)
