The BPM242 is a stereo pre-amplifier ideal for 1 and 2 zone applications where you want to have a different volume setting is needed. This pre-amplifier has 2 mono output zones and up to 6 inputs (2 MIC-line and 4 line inputs). The possibility to mix the microphone level easily with the music sources and its excellent sound quality makes it suitable for many applications like clubs, bars, restaurants…

19″ (483mm wide) rack mounting:                     Yes

height- rack units (1U=44 mm):      1U (44mm)

depth (build in):             209 mm

depth (incl front):          219 mm

MIC/Line inputs balanced:               2 (XLR 3P)

MIC input gain control:                     Yes, separately provided

MIC tone control:          Yes Bass & Treble, separately provided

inputs with Phantom power:           2 (MIC/LINE)

Phantom power voltage:                  48 volts

line input unbalanced:                       4 (RCA)

Line input gain control:                     Yes, separately provided

Line tone control:          Yes Bass & Treble

S/N Ratio:   Mic input: 65dB / Line input: 85dB

zone outputs:                 2 stereo (XLR 3P)

REC out:      Yes (RCA)

Master volume control:                    Yes, separately for both outputs

Output level meters:    5 for both outputs

Emerency input contact:                  Yes

VOX Priority:                   Yes

frequency response (in Hz):             20Hz – 20KHz

priority levels:                 4

applicable low impedance:              Yes

applicable in 100V:       Yes

power supply:                115 – 230 VAC volts

Dual AC input voltage selector:       Yes, 115V / 230V

Protection: AC Fuse

Main Construction Material –          Panel: aluminum plate / Case: steel plate

Colour:        Black

Weight:       3,9 Kg
