Frequency Response 55 Hz — 35 kHz

Sensitivity (1W@1M) 86 dB

Nominal Impedance 8 ohms

Power Handling (RMS) 100 W

Maximum SPL 106 dBA

Recommended Amplifier Requirements 25 — 100 W

Crossover Frequency 550 Hz & 3.3 kHz

System Configuration 3-Way

1 x 165 mm (6.5 inches) C-CAM mid/bass driver with RST
1 x 102 mm (4 inches) IDC mid-range driver with dual concentric 25 mm (1 inches) C-CAM Gold Dome tweeter

Dimensions (Including Frame (H x W x D)

552 x 402 x 87.5 mm (21^3/4 x 15^13/16 x 3^7/16„)

Cut-Out Dimensions

500 x 350 x 75 mm (19^11/16 x 13^3/4 x 2^15/16„)

Depth From Wall 19 mm (^3/4„)

Weight (packaged) 7.53 kg (16.6 lbs)
