Drivers:

1 Tweeter 32 mm – NdFeB motor

1 Woofer 130 mm ROHACELL® – NdFeB motor

Sensitivity:

87 dB SPL normalized to 1 m/2.83 Vrms/
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room

Low Frequency Cut Off:

69 Hz @ -3 dB/4tt sr referred to C4 WETS

Crossover Frequency:

1550Hz @ -6dB (4^th Order)

Suggested Amplifier:
Up to 100W/8Ω Average Power

Overlapping Points:

1180 Hz // LKR4 Derived (Δf=45°)

Rated Impedance:

Modulus 8 Ω (min 5.3@230Hz) Argument ±36°(20Hz-20kHz)
