Configuration:

3-way Reversed Array

Drivers:

1 Tweeter 38 mm T38 Waveguide

1 Midrange 165mm ROHACELL® –Full-Apex™ Poly-Ring NdFeB motor

2 Woofer 165 mm ROHACELL® Full-Apex™ Poly-Ring NdFeB motor

Sensitivity:

92 dBSPL normalized to 1m 2.83 Vrms
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room

Low Frequency Cut Off:

40 Hz @ -3 dB 4Ω sr referred to C4 WETS

Crossover Frequencies:

200Hz-1235Hz @ -6dB (4th Order)

Suggested Amplifier:

Up to 180W/4Ω Average Power

Rated Impedance:

Modulus 4Ω (minimum 3.6Ω @95Hz) Argument ±36° (20Hz-20kHz)

Low Frequency Load:

Down-Firing Vented

Finishing:

Solid walnut and hdf

Size:

1045 x 235 x 390 mm (H x W x D)

Weight:

30 Kg ( single piece )
