Configuration:

3-way Reversed Array

Drivers:

1 Tweeter 38mm T38Waveguide

1 Midrange 130mmROHACELL® –Full-Apex™ Poly-Ring NdFeB motor

2 Woofer 130 mm ROHACELL® Full-Apex™ Poly-Ring NdFeB motor

Sensitivity:

90 dB SPL normalized to 1 m/2.83 Vrms/
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room

Low Frequency Cut Off:

48Hz @ -3dB /4Ω sr referred to C4 WETS

Crossover Frequencies:

200Hz-1345Hz @ -6dB (4th Order)

Suggested Amplifier:

Up to 150W/4Ω Average Power

Rated Impedance:

Modulus 4Ω (minimum 2.8Ω @119Hz)

Argument ± 36° (20Hz-20kHz)

Low Frequency Load:

Down-Firing Vented

Finishing:

Solid walnut and hdf

Size:

1015 x 190 x 335 mm (H x W x D)

Weight:

20 Kg ( single piece )
